The small inlet multistage centrifugal blowers deliver optimum performance and efficiency. Available in different models, the inlet size range from 60 to 150 mm and have been designed to meet the widespread needs of the air and gas compression processing industry.
Frame 42
Inlet Flow: 85-2,050 m3/h
Discharge Pressure: 0.67 bar
Vacuum Range: 300 mmHg
Discharge Pressure: 0.67 bar
Vacuum Range: 300 mmHg
Frame 260
Inlet Flow: 170-680 m3/h
Discharge Pressure: 0.6 bar
Vacuum Range: 284 mmHg
Discharge Pressure: 0.6 bar
Vacuum Range: 284 mmHg
Frame 310
Inlet Flow: 405-765 m3/h
Discharge Pressure: 0.6 bar
Vacuum Range: 284 mmHg
Discharge Pressure: 0.6 bar
Vacuum Range: 284 mmHg
Frame 400
Inlet Flow: 120-1,785 m3/h
Discharge Pressure: 0.51 bar
Vacuum Range: 251 mmHg
Discharge Pressure: 0.51 bar
Vacuum Range: 251 mmHg
Frame 510
Inlet Flow: 255-2,210 m<3/h
Discharge Pressure: 0.81 bar
Vacuum Range: 348 mmHg
Discharge Pressure: 0.81 bar
Vacuum Range: 348 mmHg
Frame 550
Inlet Flow: 340-2,210 m3/h
Discharge Pressure: 0.81 bar
Vacuum Range: 348 mmHg
Discharge Pressure: 0.81 bar
Vacuum Range: 348 mmHg
Frame 732
Inlet Flow: 650-4,100 m3/h
Discharge Pressure: 1.05 bar
Vacuum Range: 380 mmHg
Discharge Pressure: 1.05 bar
Vacuum Range: 380 mmHg
